GDS1500D Shotcrete Concrete Pump‘s Sprayer Nozzle

concrete nozzle
  • concrete nozzle
  • concrete nozzle
  • Shotcrete nozzle
  • Shotcrete nozzle
  • Shotcrete nozzle
Model No.︰GDS1500D
Brand Name︰GEC
Country of Origin︰China
Unit Price︰-
Minimum Order︰1 pc
Share on:

 Total 5 Related Items
Prev12345Next

Product Description

 GDS1500D Shotcrete Concret Pump’s Spray Nozzle

Description:

The GDS1500D is a diesel-powered lightweight shotcrete pump run by a highly-reliable direct drive planetary gearbox and hydraulic power pack. This sturdy workhorse is made better with the added improvement of a direct drive to the carousel. The GDS1500D Direct Drive uses a 10hp diesel power pack, is skid mounted.

Feature:

·   highreliable direct drive planetary gearbox

·   infinite speed variation

·   Easily operating on site work

·   Standard spare part supply

Technical specification:

Item Description
Pressure 1.5 Mpa
Output 1.5-3m3/h
Max. Aggregate 8mm
The Squeeze Hose ID 50mm
Conveying Hose ID 38mm
Squeeze pump GH50-455
Power CFZ12 Diesel Engine, 10hp
Overall Dimension 2150x1100x1150mm
Hopper volume: 130 Liter
Weight 660kg
Requested air compressor 3m3/min, 0.5Mpa Pressure
Note: the Gasoline engine or Electric motor is optional.

 A Complete set of GDS1500D shotcrete pump

No.

Description

Qty.

Unit

Remarks

1

GDS1500D main machine

1

set



2

pump squeeze tube

1

pcs



3

conveying hose, ID38, L10m

2

pcs



4

reducer 2'/1.5'

1

pcs



5

shotcrete nozzle assy.

1

set



6

nozzle tip

1

pcs



7

air filter

1

pcs



8

clamp

1

pcs



9

clean ball

3

pcs



10

accessories

1

set



Payment Terms︰TT/LC
Lead Time︰7 days
Standards Certificate︰CE ISO
Product Image

concrete nozzle
concrete nozzle

concrete nozzle
concrete nozzle

Shotcrete nozzle
Shotcrete nozzle

Shotcrete nozzle
Shotcrete nozzle

Shotcrete nozzle
Shotcrete nozzle
