Hot-selling Medium-pressure Dual-slurry GDM60/40 Jet Injection Pump
Please copy the link to the product website for more products and information
Our website: www.gaodetec.net
Description:
Our jet injection pumps provide widely range grouting pressure selection as well as the dependability and durability required on your job site.
The jet injection pumps are ideal for grouting-process in underground and civil applications.
Features:
1. Dual-slurry grout pump
2. Single piston with double-acting
3. Gear reducer
4. Ball valve
5. Compact size
6. Iron-casting pump house
Technical data:
|
Specification:
|
|
|
Rated Output
|
60L/min
|
|
Rated Pressure
|
4MPa(40bar/580psi)
|
|
Cylinder Dia.
|
75mm
|
|
Piston Stroke
|
85mm
|
|
Stroke/Minute
|
85/min
|
|
Inlet diameter
|
38mm
|
|
Outlet diameter
|
32mm
|
|
Power unit
|
5.5KW(Electric) 10hp(Diesel)
|
|
Transmission
|
V-belt+gearbox
|
|
Chassis
|
Skid
|
|
Weight
|
210kg
|
|
Overall Dimensions
|
1280x485x645mm
|
|
Note: Single or Double Passageway are optional; Chassis: Skid or Tyre
|
A complete set of GDM 60 /40
|
No.
|
Description
|
Qty.
|
Unit
|
|
1
|
60 GROUT PUMP
|
1
|
set
|
|
2
|
Rubber piston
|
2
|
piece
|
|
3
|
Sucking hose ID51mm/2inch, L=2m
|
1
|
pcs
|
|
4
|
ID38 conveying hose,Length 10m
|
1
|
pcs
|
|
5
|
Accessorial tools
|
1
|
set
|
|
6
|
Seal parts kit
|
1
|
set
|
Contact Supplier：
Many thanks for visiting our web, we can supply grout pump for you. Before we send quotation, please let me know the following question:
1. What's pressure and flow of the pump you need ?
2. The water cement ratio, any sand in ?
3. About the power: electric (voltage and frequency) or diesel or air motor ?
We have many standard models for your option, and we also could customize as per your requirement. Please tell us your requirements and we will provide you with the corresponding product parameters and quotations. If you have any questions, please contact us.
