hose pump for Conveying of coating paint and color

concrete conveying
  • concrete conveying
  • hose pump in stock
  • Pump for Dye Making
  • conveying pump
  • conveying pump
  • concrete conveying
  • hose pump in stock
  • Pump for Dye Making
Model No.︰GH50-445C
Brand Name︰Gaodetec
Country of Origin︰China
Unit Price︰US $ 7500 / pc
Minimum Order︰1 pc
Share on:

 Total 35 Related Items
Prev2021222324Next

Product Description

Hose pump for Conveying of coating paint and color

Please copy the link to the product website for more products and information

Our website: www.gaodetec.net

Working principle:

GH series hose pump (squeeze pump) consists mainly of pump house, rotor, roller, idle roller, squeeze tube and driving unit. The squeeze hose is U-shape in pump hose, when rotor drives roller to rotate, hose is deformed. After the roller rotate, the deformed hose recover by its elasticity. Thus the negative pressure in this hose is generated, sucking slurries, and discharging through outlet under roller’s push, finally forms pressure conveying of slurries.

Application:

Since 1998, we have become main supplier of pump head for one of world’s famous hose pump manufacturer. From recent years, we are also providing matched hose pumps for TBM machine manufacturer in China. Our hose pumps are widely applied in architecture, underground construction, petrochemical industry, metallurgy, food industry, ceramic, mining, water treatment, pharmacy, and papermaking.

Advantage:

No seals

No valves

Self -priming

Only tube to replace

Dry –running without damage

Reversible

No contact between product and mechanical parts

Able to pump products with solid parts inside

Easy maintenance, low-cost, short down time

Technical data sheet:

Type

GH50-445C

Max. ouput

3.7m3/h

Rotation

30 RPM

Squeeze hose ID

50mm

Working pressure

30 bar

Voltage

3 phase, 380V, 50HZ

Power

5.5 KW

Contact Supplier:

We are the industrial hose pump factorywe can customize according to your requirements. If you have any questions, please contact us and we will provide you with the corresponding product parameters and quotations.

1. What is the project with our peristaltic pump, is it for pumping concrete or others?

2. What is the pressure and output you require?

3. What is the local voltage you require, here the voltage 380V, 50HZ, 3phase, is it ok for you?

4. What is max. aggregate size in the slurry?

FAQ:

1. Q: What's the output of hose pump?

     A: 60-42000L/h, if need, we also ca according your demands to redesign the pump

2.  Q: What's the running parts?

     A: The squeeze hoe is the only consumpation part.

         Now we have three types hose for choose, Chinese hose, Britain hose, and Trelleborg hose.

3.  Q: What's the filed of the pump applied in?

     A: Our hose pumps are widely applied in architecture, underground construction, petrochemical industry, metallurgy, food industry, ceramic, mining, water treatment,  pharmacy, and papermaking.



Payment Terms︰TT/LC
Packing︰plastic wrap, plywood case, free-gumigation, standard export packing. as shown below. Or customised.
Lead Time︰in stock. common type 7 working days after confirm
Standards Certificate︰CE ISO
