GH-HD Series Grouting Pump for metro project

grouting pump
  • grouting pump
  • jet grout pump
  • jet grout pump
  • grout pump for metro
  • grout pump for metro
Model No.︰GH-HD
Brand Name︰Gaodetec
Country of Origin︰China
Unit Price︰US $ 9990 / pc
Minimum Order︰1 pc
Share on:

 Total 33 Related Items
Prev2930313233Next

Product Description

GH-HD Series Grouting Pump for metro project

Please copy the link to the product website for more products and information

Our website: www.gaodetec.net

GH-HD series hydraulic mine grout pump is suitable for grouting plugging project of high pressure and large displacement. This pump transmits pressure signals by working medium (slurry and hydraulic oil) to form closed-loop automatic control function, therefore the pump is simple in structure, can regulate timely and accurately, and has no overpressure problem.

This pump can adjust its output and working pressure by continuously Variable adjustment, and has the function of automatic regulating output according to the pre-seted grouting final pressure. The pump can grout simple-liquid, dual-liquid and chemical grout. The pump is equipped dual-liquid regulator(patented).

The technology originally comes from Japan, and is updated by us, right now, our GH-HD series grout pumps have new characteristics as follows:

  1. New technical hydraulic system with smooth shift and reliable work.
  2. Volume and weight are about the half of the original Japanese pump.
  3. Equipped with large capacity hydraulic accumulator, no impact in shift
  4. Equipped with large size water cooler, can work continuously for a long time.
  5. Operation and maintenance are simple.
  6. With ISO,CE certificate

Technical data:

                            7.5kw High Pressure Grout Pump

Power(kw)

Overall Dimension

Weight(kg)

Aggregate

Pump Slurry Ratio

Hydraulic oil tank

7.5

1.2×0.7×1.1m

360

≤Φ3mm

0.5:1~1:1(W/C)

100L

Power(kw)

Model

Output(L/Min)

Pressure(Mpa)

7.5

GH140/6-7.5HD

≤140

≤6

GH120/7-7.5HD

≤120

≤7

GH100/9-7.5HD

≤100

≤9

GH80/11-7.5HD

≤80

≤11

GH66/13-7.5HD

≤66

≤13

GH60/15-7.5HD

≤60

≤15

GH50/18-7.5HD

≤50

≤18

GH40/22-7.5HD

≤40

≤22

Accessories

Suction hose,filter, delivery hose, junction device, tools, sealing parts bit.                                          Optional: thickness slurry hopper, hole plug, mixture ratio regulator, baume gauge.

                            15kw,18.5kw dual slurry grout pump

Power(kw)

Overall Dimension

Weight(kg)

Aggregate

Pump Slurry Ratio

Hydraulic oil tank

15,18.5

1.4×0.8×1.3m

560,630

≤Φ3mm

0.5:1~1:1(W/C)

200L

Power(kw)

Model

Output(L/Min)

Pressure(Mpa)

15

GH210/8-15HD

≤210

≤8

GH190/10-15HD

≤190

≤10

GH150/12-15HD

≤150

≤12

GH120/15-15HD

≤120

≤15

GH100/17-15HD

≤100

≤17

GH80/24-15HD

≤80

≤24

GH60/30-15HD

≤60

≤30

18.5

GH210/9-18.5HD

≤210

≤9

GH190/11-18.5HD

≤190

≤11

GH150/14-18.5HD

≤150

≤14

GH120/17-18.5HD

≤120

≤17

GH100/20-18.5HD

≤100

≤20

GH90/23-18.5HD

≤90

≤23

GH80/28-18.5HD

≤80

≤28

GH60/33-18.5HD

≤60

≤33

Accessories

Suction hose,filter, delivery hose, junction device, tools, sealing parts bit.                                          Optional: thickness slurry hopper, hole plug, mixture ratio regulator, baume gauge.

                           22kw,37kw dual slurry grout pump



Power(kw)

Overall Dimension

Weight(kg)

Aggregate

Pump Slurry Ratio

Hydraulic oil tank



22,37

2.0×1.35×1.5m

1000, 1200

≤Φ3mm

0.5:1~1:1(W/C)

300L



Power(kw)

Model

Output(L/Min)

Pressure(Mpa)



22

GH320/8-22HD

≤320

≤8



GH270/9-22HD

≤270

≤9



GH220/11-22HD

≤220

≤11



GH180/14-22HD

≤180

≤14



GH140/18-22HD

≤140

≤18



GH120/20-22HD

≤120

≤20



GH100/24-22HD

≤100

≤24



GH95/28-22HD

≤95

≤28



GH80/34-22HD

≤80

≤34



37

GH320/10-37HD

≤320

≤10



GH270/12-37HD

≤270

≤12



GH220/15-37HD

≤220

≤15



GH180/18-37HD

≤180

≤18



GH140/23-37HD

≤140

≤23



GH120/26-37HD

≤120

≤26



GH100/31-37HD

≤100

≤31



GH95/37-37HD

≤95

≤37



GH80/45-37HD

≤80

≤45



Accessories

Suction hose,filter, delivery hose, junction device, tools, sealing parts bit.                                                                                                               Optional: thickness slurry hopper, hole plug, mixture ratio regulator, baume gauge.



Contact Supplier:

Many thanks for visiting our web, we can supply grout pump for you. Before we send quotation, please let me know the following question:


1. What's pressure and flow of the pump you need ?
2. The water cement ratio, any sand in ?
3. About the power: electric (voltage and frequency) or diesel or air motor ?


We have many standard models for your option, and we also could customize as per your requirement. Please tell us your requirements and we will provide you with the corresponding product parameters and quotations. If you have any questions, please contact us.

Payment Terms︰T/T L/C
Packing︰plastic wrap, plywood case, free-gumigation, standard export packing. as shown below. Or customized.
Lead Time︰in stock. common type 7 working days after confirm
Standards Certificate︰CE ISO
