JBT40 L2 Trailer concrete pump with forced mixer

electric mobile concrete mixer pump
  • electric mobile concrete mixer pump
  • concrete mixing pump machine
  • mix concrete pump for sale
  • concrete mixer pump in zambia
  • concrete mixer and pump
  • Concrete Pump with Mixer Machine
  • mixing concrete pump on sale
  • small concrete mixer pump
Model No.︰JBT40 L2
Brand Name︰Gaodetec
Country of Origin︰China
Unit Price︰US $ 36000 / set
Minimum Order︰1 set
Share on:

 Total 6 Related Items
Prev12345Next

Product Description

Description of trailer concrete mixing pump

Trailer concrete pump with forced mixer is combined by the traditional concrete pump and the mixer together. It achieves full automatic during concrete construction process.

Application of trailer concrete mixing pump

Convey floor heating lightweight foamed cement, mortar, fine aggregate concrete.
Convey greening soil in ecological environment construction.
Convey all kinds of engineering construction in the plain concrete, fiber concrete.
Most suitable for four to six floor buildings, especially in the group buildings, bridges and the small construction sites where need the concrete mixer at the scene.

Features of trailer concrete mixing pump

1. Innovation, mixer can be pushed and pulled, moving more safely.
2. Transfer concrete through pipeline. It is fast and safe.
3. It has small size and suitable for more special environment.
4. Optional part: cement boom, wireless remote control. This is easy to operate.
5. Compulsive mixing, high quality, high efficiency.
6. Optional batching machine, setting up the materials faster, Well-proportioned and efficient.

Technical data of trailer concrete mixing pump

Parameters

JBT40 L2

Main oil pump

Domestic / Kawasaki 112

Mixer model

JS 500

The maximum theoretical delivery output

40m3/h

The maximum theoretical mix output

28m3/h

Vertical pumping distance

70m

Horizontal pumping distance

300m

Main oil cylinder / Rod * Stroke

100*70*800

Distribution valve type

S valve

Main motor

37kw

Outlet pressure

7Mpa

Hydraulic system type

Open system

Oil Cylinder * Rod * Stroke

100*70*100

Delivery Cylinder * Stroke

200*1000

Hopper Capacity * Filling Height

600*1050

Motor voltage

380V

Hoist motor

5.5kw

Mixing motor

18.5kw

Concrete Outlet Diameter

200mm

Max. aggregate size

Pebble 40mm; Crushed stone:30

Weight

5300kg

Dimension

 7300*2210*2500mm

Payment Terms︰TT / LC
Packing︰container delivery or as requested
Lead Time︰10 working days.
Standards Certificate︰ISO
Product Image

electric mobile concrete mixer pump
electric mobile concrete mixer pump

concrete mixing pump machine
concrete mixing pump machine

mix concrete pump for sale
mix concrete pump for sale

concrete mixer pump in zambia
concrete mixer pump in zambia

concrete mixer and pump
concrete mixer and pump

Concrete Pump with Mixer Machine
Concrete Pump with Mixer Machine

mixing concrete pump on sale
mixing concrete pump on sale

small concrete mixer pump
small concrete mixer pump
