electric cement grouting machine compact grout mixer Pump for sale in Bauma

grout station
  • grout station
  • electric cement grouting machine compact grout mixer Pump for sale in Bauma
  • electric cement grouting machine compact grout mixer Pump for sale in Bauma
  • grout station
  • grout station
  • grout station
  • grout station
  • grout station
  • grout station
  • grout station
  • grout station
  • grout station
Model No.︰GGP300/300/75
Brand Name︰Gaodetec
Country of Origin︰China
Unit Price︰US $ 9500 / set
Minimum Order︰1 set
Share on:

 Total 73 Related Items
Prev3233343536Next

Product Description

Electric cement grouting machine compact grout mixer Pump for sale in Bauma

Compact grout mixer pump feature:

1. Hydraulic reversing and Hydraulic drive for Vertical grouting pump;

2. Grouting pressure and output are step-less adjustable;

3. Using rectangular agitator, makes the plant has compact structure, small size;

4. Grouting pump has high speed and low speed by rotating ball valve switch;

5. With the function of record and display grouting pump reciprocating times by a counter;

6. With a air cooler and a water cooler, to adapt to different working environment temperature;

7. Mixer and agitator switch is a squeeze handle that is easy to operate and reliable;

Compact grout mixer pump application:

1. Civil Engineering - dam foundations, tunnels, mining, soil nails, tiebacks, earth anchors, cable and rock bolts;

2. Structural – building and bridge restoration, foundation stabilization, foundation raising, soil compaction grouting; soil & rock grouting;

3. Construction - pavement under sealing, slab jacking and slab raising;

4. Marine - underwater foundations, piers, breakers, shoreline foundations;

5. Mining - tunnel lining, contact grouting, shaft waterproofing;

6. Utilities - encasements, waterproofing, slope line grouting;

7. Geotechnical - deep well casing, monitor wells, well sealing and abandonment;

Compact grout mixer pump technical data:

Description

Data

Grout grout mixer pump type

GGP300/300/75PI-E

Mixer Volume

300L

Mixer production(w/c ratio=1)

4.5m3/h

Circulation capacity

1100l/min

Suitable W/C Ratio

0.5 to 1

Mixer electric motor power

7.5kw, 1450rpm

Agitator Volume

300L

Agitator Speed

36rpm

Agitator electric motor power

1.5kw, 1450rpm

Grout Pump Type

piston grout pump

Grout pump output and pressure

0-75L/min, 0-5Mpa(high-speed)
 0-38L/min, 0-10MPa(low-speed)

Grout pump electric motor power

11kw, 1450rpm

Grout Mixer Pump Overall dimension

2330x1260x1790mm

Grout Mixer Pump Weight

1125kgs

 Contact Supplier:

Many thanks for visiting our web, we can supply grout station for you. Before we send quotation, please let me know the following question:

1. How about the flow and pressure of the pump you want, please?

2. How about the water and cement ratio, does any sand in?

3. About the power: electric (voltage and frequency) or diesel?

Please tell us your requirements and we will provide you with the corresponding product parameters and quotations. We have many standard models for your option, and we also could customize as per your requirement. If you have any questions, please contact us.

Payment Terms︰TT/LC
Packing︰plastic wrap, plywood case, free-fumigation, standard export packing. as shown below. Or customized.
Lead Time︰in stock. common type 7 working days once confirm
Standards Certificate︰CE ISO
