GZ-5D Dry Shotcrete Machine Description:
GZ-5D shotcrete machine is medium-sized shotcrete machine for the processing of dry mix. And widely used by so many contractors.
Product Parameter:
|
Output Capacity
|
3-5.5m3 /h
|
|
Max. Horizontal Conveying Distance
|
200m
|
|
Suitable Mix Ratio(Cement/Sand)
|
≤1:4~5
|
|
Water cement ratio
|
<0.4
|
|
Max. Aggregate Size
|
Dia.15 mm
|
|
Conveying Hose Inner Diameter
|
Dia.51 mm
|
|
Operating air Pressure
|
0.2-0.4MPa(29-58PSI)
|
|
Air Consumption
|
9m3/min(325CFM)
|
|
Material Charging Height
|
1.1m
|
|
Rotor Speed
|
11r/min
|
|
Diesel Type
|
CF1105M
|
|
Power
|
13kw/18hp
|
|
Overall Dimension(L× W× H)
|
2.2×0.96×1.2m
|
|
Net Weight
|
850kg
|
GZ-5D Dry Shotcrete Machine Application:
1. Tunnel linings.
2. Mining operations.
3. Hydropower projects.
4. Hill side projects.
5. Swimming Pool.
6. Concrete repair.
7. Soil retention and retaining walls.
8. Underground excavation engineering etc.
GZ-5D Dry shotcrete machine Features:
1. Variable output with variable-frequency drive.
2. Heavy-duty solid wheels.
3. Coulping and clamp.
4. Light weight nozzle.
5. WEG motor, Support global service.
GZ-5D dry shotcrete machine Advantage:
1. High quality, reliable performance.
2. Good seal performance, little dust.
3. Reasonable design, convenient to move.
4. Convenient operation and longevity of service.
5. Non-adhesion going-through rotor with new material chamber, completely eliminate bonding and blocking during operation so as to reduce clearance and maintenance period.
6. Thin flow conveying method with vortex flow, so the spraying flow is even, continuous and steady, to improve the shotcrete quality.
7. Four-point clamping device make it easy to adjust the press between sealing plate and rotor disk so as to no air and dusk leak and prolong consumption parts life.
8. Widely used in mining, tunnel, culvert, revetment etc.
GZ-5 series dry shotcrete machine is available in following versions:
Basic: Electric drive can be combined with tyre chassis
Extended (optional): Electric motor drive with variable speed gearbox, air motor drive or diesel drive combined with Skid or Rail-wheel.
GZ-5 series dry shotcrete machine main technical data:
Electric motor drive:
|
Electric Motor Type
|
WEG motor
|
|
Rated Output
|
5m 3 /h
|
|
Max. Horizontal Conveying Distance
|
200m
|
|
Suitable Mix Ratio(Cement/Sand)
|
≤ 1:3~5
|
|
Water Cement Ratio
|
< 0.4
|
|
Max. Aggregate Size
|
Φ 15 mm
|
|
Conveying Hose Inner Diameter
|
51mm
|
|
Operating air Pressure
|
0.2-0.4MPa(29-58PSI)
|
|
Air Consumption
|
8~9m 3 /min(285-325CFM)
|
|
Motor Power
|
5.5kW(7.5hp)
|
|
Voltage
|
220V, 380V, 440V, 660V, 50Hz/60Hz
|
|
Material Charging Height
|
1.1m
|
|
Rotor Speed
|
11r/min
|
|
Overall Dimension(L* W*H)
|
1.35× 0.75× 1.2m
|
|
Net Weight
|
720kg
|
You also have the following option:
With variable gearbox:
|
Output Capacity
|
1-5m ³/h
|
|
Max. horizontal conveying distance
|
200m
|
|
Suitable mix ratio (cement/sand)
|
≤1:4-5
|
|
Max. aggregate size
|
15mm
|
|
conveying hose inner diameter
|
51mm
|
|
Conveying pressure
|
0.2-0.4MPa
|
|
Air consumption
|
7-8m ³/min
|
|
Material charging height
|
1.1m
|
|
Rotor speed
|
2.2-11r/min
|
|
Electric motor type
|
Y132M-4
|
|
power
|
7.5kW/10hp
|
|
Overall dimension (length×width×height)
|
1.42×0.75×1.2m
|
|
Net weight
|
750kg
|
|
Output Capacity
|
2.5-5.5m3 /h
|
|
Max. Horizontal Conveying Distance
|
200m
|
|
Suitable Mix Ratio(Cement/Sand)
|
≤1:3~5
|
|
Max. Aggregate Size
|
Φ15 mm
|
|
Conveying Hose Inner Diameter
|
Φ51 mm
|
|
Conveying Pressure
|
0.2-0.4MPa
|
|
Air Consumption for conveying material
|
7~8m3/min
|
|
Air Motor Air Pressure
|
0.5MPa
|
|
Material Charging Height
|
1.1m
|
|
Rotor Speed
|
11rpm
|
|
Air Motor Type
|
TMH6A
|
|
Air Motor Air Consumption
|
7.5m3/min
|
|
Overall Dimension(L*W*H)
|
1.35×0.75×1.2m
|
|
Net Weight
|
720kg
|
