energy saving and high strength GF20D diesel engine cement foam machine

clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
  • clc making machine
Model No.︰GF20D
Brand Name︰Gaodetec
Country of Origin︰China
Unit Price︰US $ 5800 / pc
Minimum Order︰1 pc
Share on:

 Total 40 Related Items
Prev12345Next

Product Description

energy saving and high strength GF20D diesel engine cement foam machine

GF20D foam concrete machine includes A Belt Conveyor, A Concrete Mixer, A Foam Generator and A Hydraulic Piston Pump, adopts centralized control technology, can exactly adjust the density of foam cement. The capacity is 20m3/h, Max. Horizontal pumping distance is 500m, Max. vertical pumping distance is 80m, Max. Aggregate size is 3mm, suitable for filoor and roof insulation.



Model

GF20

GF30

GF40

The theoretical output (m³/h)

20

25-30

40

Max. convening distance(m)

Horizontal

500

500

1200

Vertical

80

80

160

Voltage

3 phase,380V,50Hz

3 phase,380V,50Hz

3 phase,380V,50Hz

Total motor power(kw)

21

21

47

Mixing tank capacity (L)

580

580

735L

Filling height (mm)

1100

1100

1100

Over dimension(mm)

3000*1420*830

2200*1540*1760

2800*1650*1760

Payment Terms︰TT / LC / DP / DA
Packing︰Wooden packing
Lead Time︰15
Standards Certificate︰ISO CE
Product Image

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine

clc making machine
clc making machine
