GH76-915B heavy- duty industries hose pump (squeeze pump) is a kind of peristaltic pump. Max. Output is 20m3/h, the working pressure is 7.5bar.
An elastomeric tube is squeezed along a length by rollers. The tube's restitution after squeezing produces a vacuum that draws fluid continuously into the tube. That doesn't cause any damage to the product. And contaminations are avoided.
In building construction, more widely used for pumping foam concrete, lightweight form concrete, mortar, cement slurry and refractory materials.
|
Type
|
GH76-915B
|
|
Max.Output
|
20 m3/h
|
|
Rotation
|
40 RPM
|
|
Squeeze Hose ID
|
76 mm
|
|
Pressure
|
1.0Mpa
|
|
Motor Power
|
18.5 kw
|
|
Max.Aggregate Size
|
15 mm
|
|
Weight
|
1000 kg
|
|
Max.Suction Lift
|
5 m
|
Contact Supplier:
We are the industrial hose pump factory, we can customize according to your requirements. If you have any questions, please contact us and we will provide you with the corresponding product parameters and quotations.
1. What is the project with our peristaltic pump, is it for pumping concrete or others?
2. What is the pressure and output you require?
3. What is the local voltage you require, here the voltage 380V, 50HZ, 3phase, is it ok for you?
4. What is max. aggregate size in the slurry?
GH series hose pump models:
|
Pump mode
|
Output
l/h
|
Pressure
MPa
|
Hose ID
mm
|
Rev.
r/mm
|
Max.
Particle Dia
mm
|
Max.
Suct.Left
m
|
Motor Power
kw
|
|
GH10
|
60
|
0.6
|
10
|
45
|
2
|
2
|
0.37
|
|
GH10B
|
100
|
0.6
|
10
|
80
|
2
|
2
|
0.37
|
|
GH15
|
210
|
0.6
|
15
|
45
|
2
|
2
|
0.55
|
|
GH15B
|
300
|
0.6
|
15
|
75
|
2
|
2
|
0.55
|
|
GH25
|
800
|
1.5
|
25
|
50
|
3
|
3
|
1.1
|
|
GH25B
|
1300
|
1.5
|
25
|
80
|
3
|
3
|
1.5
|
|
GH32
|
1300
|
1.5
|
32
|
50
|
3
|
4
|
2.2
|
|
GH32B
|
1800
|
1.5
|
32
|
75
|
3
|
4
|
2.2
|
|
GH38
|
2000
|
1.5
|
38
|
40
|
5
|
4
|
2.2
|
|
GH38B
|
2700
|
1.5
|
38
|
55
|
5
|
4
|
3.0
|
|
GH38C
|
3500
|
1.5
|
38
|
70
|
5
|
4
|
4.0
|
|
GH50-558
|
4200
|
1.5
|
51
|
35
|
6
|
5
|
4.0
|
|
GH50-558B
|
5400
|
1.5
|
51
|
45
|
6
|
5
|
5.5
|
|
GH50-680
|
6300
|
1.5
|
51
|
35
|
6
|
5
|
7.5
|
|
GH50-680B
|
8000
|
1.5
|
51
|
45
|
6
|
5
|
7.5
|
|
GH65-680
|
9200
|
1.2
|
64
|
40
|
8
|
5
|
7.5
|
|
GH65-680B
|
12000
|
1.5
|
64
|
45
|
8
|
5
|
11.0
|
|
GH65-770
|
13500
|
1.2
|
64
|
45
|
8
|
5
|
11.0
|
|
GH65-770B
|
16500
|
1.0
|
64
|
55
|
8
|
5
|
11.0
|
|
GH76-770
|
18000
|
1.0
|
76
|
45
|
10
|
5
|
11.0
|
|
GH76-770B
|
22000
|
1.0
|
76
|
55
|
10
|
5
|
15.0
|
|
GH76-915
|
24000
|
1.0
|
76
|
50
|
10
|
5
|
15.0
|
|
GH76-915B
|
28000
|
1.0
|
76
|
40
|
10
|
5
|
18.0
|
|
GH100
|
33500
|
1.0
|
102
|
35
|
15
|
5
|
18.0
|
|
GH100B
|
42000
|
0.75
|
102
|
45
|
15
|
5
|
18.0
|
