Small Grout Equipment for sale to Indoenisa
Small grout equipment for sale feature:
1. Grouting pressure, displacement is stepless adjustable;
2. Simple structure, light weight, easy maintenance;
3. Double grouting cylinder, continuous output with small pulse;
4. Less spare parts ensure low maintenance costs;
5. High speed vortex mixer ensures mix quickly and evenly;
6. Mixer and agitator switch by using squeeze handle, it is safe, reliable and easy to operate;
7. The motor has an overload protection function. Hydraulic system with oil temperature overheating protection;
8. With CE, ISO certification.
Small grout equipment for sale application:
1. Civil Engineering - dam foundations, tunnels, mining, soil nails, tiebacks, earth anchors, cable and rock bolts;
2. Structural – building and bridge restoration, foundation stabilization, foundation raising, soil compaction grouting; soil & rock grouting;
3. Construction - pavement under sealing, slab jacking and slab raising;
4. Marine - underwater foundations, piers, breakers, shoreline foundations;
5. Mining - tunnel lining, contact grouting, shaft waterproofing;
6. Utilities - encasements, waterproofing, slope line grouting;
7. Geotechnical - deep well casing, monitor wells, well sealing and abandonment;
Small grout equipment for sale technical data:
Description
|
Data
|
Grout plant type
|
GGP500/700/100PI-E
|
Mixer Volume
|
500L
|
Mixer production(w/c ratio=1)
|
7m3/h
|
Circulation capacity
|
1100l/min
|
Suitable W/C Ratio
|
0.5 to 1
|
Mixer electric motor power
|
7.5kw, 1450rpm
|
Agitator Volume
|
700L
|
Agitator Speed
|
36rpm
|
Agitator electric motor power
|
1.5kw, 1450rpm
|
Grout Pump Type
|
piston grout pump
|
Grout pump output and pressure
|
0-100L/min
0-5Mpa
|
Grout pump electric motor power
|
15kw, 1450rpm
|
Grout Equipment Overall dimension
|
2700x175x1650mm
|
Grout Equipment Weight
|
1440kgs
|
