GDB 100/10Q crankshaft grouting pump

  • GDB 100/10Q crankshaft grouting pump
  • GDB 100/10Q crankshaft grouting pump
  • GDB 100/10Q crankshaft grouting pump
  • GDB 100/10Q crankshaft grouting pump
  • GDB 100/10Q crankshaft grouting pump
Model No.︰GDB100/10Q
Brand Name︰Gaodetec
Country of Origin︰China
Unit Price︰US $ 5800 / pc
Minimum Order︰1 pc
Share on:

 Total 38 Related Items
Prev2122232425Next

Product Description

GDB 100/10Q crankshaft grouting pump

Description:

GDB100/10Q  crankshaft injection grouting pump is the special equipment of grouting cement and mortar. It is mainly used in grouting curtain , concretion grouting and so on. The pump have strong adaptability with high density and high pressure grouting curtain and injecting mortar (diameter<2mm). They can be widely used in various foundation construction.

Feature:

1.maintenance and changing the components are convenient.

2. adopting interchangeable parts, such as link lever in the car ,bearing bush ,sheet steel in the autocycle,friction disc and so on.

3. plunger rod and plunger head are the dismountable joint , so it can avoid serous fluid and water enter into the compound box.

4.The struction of planet reducer device is compact, so it is convenient and durable.

Technical data:

model

GDB100/10Q

type

single acting pump with three-cylinder

plunger   diameter

63mm

rated   pressure

10Mpa

theoretical   displacement

100L/min

medium   ratio(water:ash:sand)

1:2:2

input pipe diameter

64mm

output pipe diameter

25mm

motor power

18.5kw

weight

650kg

dimension(L*W*H)

1700*742*685mm

Payment Terms︰T/T L/C
Packing︰plastic wrap, plywood case, free-gumigation, standard export packing. as shown below. Or customized.
Lead Time︰in stock. common type 7 working days after confirm
Standards Certificate︰CE ISO
